Elecbee EB-JYB-KO-L Submersible Deep Well Liquid Level Transmitter

SKU: EB-JYB-KO-L

Favorites

Key Features

Features:

1. All adopt low power consumption and high reliability design

2. Meet the measurement and control requirements of multiple physical quantities

3. Sensitive components are all imported high-precision components

4. Industrial-grade design ensures long-term stability for on-site use

5. Large-scale production ensures consistency of product performance

Specifications

Show Similar Products >

Attribute

Value

Tool Type

液位变送器

Show Similar Products >

Shipping Guide

Shipping	Delivery Period	For in-stock parts, orders are estimated to ship out in 3 days. Elecbee ships orders once a day at about 5pm except Sunday. Once shipped, estimated delivery time depends on the below carriers you chose. DHL Express: 3-7 business days DHLeCommerce: 12-22 business days FedEx International Priority: 3-7 business days EMS: 10-15 business days Registered Air Mail: 15-30 business days
	Shipping Rates	Shipping rates for your order can be found in the shopping cart.
	Shipping Options	Shipping rates for your order can be found in the shopping cart.
	Shipping Tracking	We will notify you by email with tracking number once order is shipped. You can track your order using the “Track My Order” feature.
Returning/Warranty	Returning	Returns are normally accepted when completed within 30 days from date of shipment, please contact customer service for a return authorization. Parts should be unused and in original packaging. Customer has to take charge for the shipping
	Warranty	All Elecbee purchases come with a 30-day money-back return policy, plus 1-year Elecbee warranty against any manufacturing defects.
		This warranty shall not apply to any item where defects have been caused by improper customer assembly failure by customer to follow instructions, product modification, negligent or improper operation
Ordering	How to Buy	Elecbee accepts online orders.
		Add to cart > Check out > Submit order > Complete payment > Delivery
	Payment	PayPal, Credit Card includes Visa, Master, American Express, Bank transfer.

Description

Level transmitters are instruments that provide continuous level measurement. They measure levels of media, such as water, viscous fluids, and fuels. In every process industry, a level transmitter is vital to prevent overflow. Different types of level transmitters are used based on the process media condition.

The working principle of level transmitters varies according to their underlying principle. But, all level transmitters measure the level in one of three ways:

The weight of the fluid

The pressure head of the fluid

The position of the fluid in a container

Level transmitters are classified as direct, indirect, contact, or non-contact. Direct-level measurements are ideal for small-level changes observed in various industrial tanks. Yet, most level transmitters are designed for indirect level measurements.

Technical Parameters：

Model No.	EB-JYB-KO-L
Measuring Range	Various measuring ranges within 300m~1000m
Level of Accuracy	Level 0.5 (300m～1000m)
Level of Accuracy	Level 0.2 (300m～500m)
Medium Temperature	-20℃～70℃
Ambient Temperature	-20℃～60℃
Output Form	4mA ～ 20mA、0V ～ 5V、RS-485
Supply voltage	DC 24V（12V～32V）
Load Capacity	Current output type: ≤500Ω
Nonlinear	±0.2％F.S
Insulation Resistance	＞100MΩ
Hysteresis and Repeatability	±0.1％F.S
Years of Long-term Stability	±0.1％F.S
Thermal Zero Point Drifts per Degree	±0.03％F.S
Response Time	≤50ms
Overload Pressure	2 times range
Electrical Connections	Stainless steel cable connection
Housing Material	Stainless steel/316 stainless steel
Measuring Medium	Oil, water and other media compatible with 316 stainless steel
EMC Level	Level three
Protection Level	IP68
